CAD and 3D Modeling
Ashlar-Vellum CAD and 3D Modeling products include:
- Graphite™ for 2D/3D Drafting
- Cobalt™ for Parametric 3D Modeling
- Xenon™ for Associative 3D Modeling
- Argon™ for History-free 3D Modeling
Click a product to learn more about it.
Ashlar-Vellum Product Chart
| Features | Graphite Subs 1 yr. $395 |
Lithium Subs 1 yr. $95 |
Cobalt Subs 1 yr. $595 |
Xenon Subs 1 yr. $395 |
Argon Subs 1 yr. $295 |
|---|---|---|---|---|---|
| Integrated Design Environment: &Wires, Surfaces, Solids | |||||
| 2D & 3D Production Drafting | |||||
| Associative Parametrics | |||||
| Geometric- & Equation-driven Parametrics | |||||
| Detail and Auxiliary Views | |||||
| Section Views | |||||
| Associativity & Work Flow History | |||||
| 3D Rendering, Visualization & Animation |
|||||
| Associative Assembly Tools | |||||
| Bill of Materials | |||||
| CAM/RPT Output | 2D | 2D | 2D/3D | 2D/3D | 2D/3D |
| Mechanical Parts Library | 2D | 3D | |||
| Geometric Dimensioning & Tolerancing (GDT) |
