System Requirements

  • Windows / macOS
  • Windows x64 10 / 11 (Intel and AMD)
  • macOS 10.13 (High Sierra) / 10.14 (Mojave) / 10.15 (Catalina) / 11 (Big Sur)* / 12 (Monterey)* / 13 (Ventura)* / 14 (Sonoma)*
  • OpenGL 3.3 compatible Video Card Required / Medium- to High-performance Graphics Subsystem Recommend
  • 2 GB RAM Required / 8 GB Recommended
  • 2 GB free hard drive space Required / 4+ GB SSD Recommended
  • Internet Connection

*Apple silicon is supported via Rosetta2 which is included free by Apple in macOS 11, 12, and 13 for Apple silicon based Macs


For Anti-Piracy:
  • Periodic Internet Communications (once every 30 days) OR
  • CodeMeter Security Key in USB Port, SD Card Slot or microSD Card Slot on a Local or Network Computer. (Sold separately. Be sure to order the correct key. USB keys may be ordered from Ashlar-Vellum. SD and microSD keys must be ordered directly from CodeMeter.)
For Installation:
  • Internet Connection
