Ashlar-Vellum Precision 3D File Import Capabilities

Built into Cobalt™, Xenon™ and Argon™

  • ACIS *.sat, R1.5-16
  • AutoCAD *.dwg & *.dxf , Version 12-2007
  • IGES *.iges,*.igs, up to Version 5.3
  • STEP*.stp, AP203-AP214
  • Parasolid X_T Parasolid *.x_t, *.x_b, V7-V12(Windows Only)
  • Catia v4*.model, *.exp, *.dlv
  • Rhino 3DM *.3dm
  • Grid Surface Text File *.dat
  • Other Ashlar-Vellum Products *.co, *.xe, *.ar, *.vc6, *.vlm, *.vs

Available with Alchemy:Essential™

  • SolidWorks *.sldasm & *.sldprt, Version 98-2009
  • Inventor *.ipt, & *.iam, up to Version 2010
  • Catia v4 *.model, *.exp, *.dat, *.session, Sequential Files
  • ACIS .sat, R2-R19
  • Parasolid .x_t, V10-V20
  • STEP .stp, AP203-AP214
  • IGES .igs, up to Version 5.3

Available with Alchemy:Adept™

  • Catia v5 *.CATpart & *.CATproduct, R6-R19
  • Pro/ENGINEER *.prt, & *.asm, V16-2001, and Wildfire 3 & 4
  • Siemens Unigraphics .prt, V11-18, NX to NX6
  • SolidWorks *.sldasm & *.sldprt, Version 98-2009
  • Inventor *.ipt, & *.iam, up to Version 2010
  • Catia v4 *.model, *.exp, *.dat, *.session, Sequential Files
  • ACIS .sat, R2-R19
  • Parasolid .x_t, V10-V20
  • STEP .stp, AP203-AP214
  • IGES .igs, up to Version 5.3
