Precision CAD & 3D Modeling Perfect for Use throughout an Organization

Because of our superior ease of use and adaptability, any of our software products can be deployed further throughout an organization. No longer will your most creative thinkers resort to pen and paper just to get the job done. Ashlar-Vellum software is ideal of those needing extremely powerful precision wire-frame 2D/3D drafting or free-flow 3D modeling that’s easy enough to use even on an occasional basis.

Full Drawing Software Works with Your Markup Program

Our software programs are not review and redline programs like Actify’s SpinFire or Cimmetry’s AutoVue. They are full drawing and modeling package that can be used in collaboration with these programs for consistency across your organization.


Choice of Platforms: Mac, Windows, or Linux

No longer will the Mac people fight with the Windows people and gang up against the Linux crowd. Ashlar-Vellum software supports them all with interchangeable file types. Users can switch versions at no additional cost. Linux version is available exclusively for Enterprise clients at the Corporate and Global level.

Upgrades Included

Both service pack updates and major upgrades are included in the annual fee. All new releases can be downloaded from the website. For an additional fee, DVDs can be shipped to designated locations.

2D & 3D CAD Support for 10 Languages

A single installer supports ten localized languages including:

  • English (US)
  • English (UK)
  • French
  • German
  • Italian
  • Portuguese
  • Swedish
  • Spanish
  • Japanese
  • Russian

Languages can be changed at runtime without re-installing.
